Industrial Filter Pump
22000.00 INR/Set
Product Details:
- Mounting Type Base Mounted
- Flow Rate 50-100 L/min
- Voltage 220/380V
- Control System Manual / Automatic
- Caliber 25 mm
- Working Temperature -10C to 80C
- Max Suction 3-4 meter
- Click to View more
X
Industrial Filter Pump Price And Quantity
- 01 Set
- 22000.00 INR/Set
Industrial Filter Pump Product Specifications
- Industrial Filtration
- Self-priming
- Base Mounted
- PP (Polypropylene) / PVDF
- 220/380V
- Manual / Automatic
- 50-100 L/min
- Filter Pump
- Electroplating, Chemical Process, Industrial Water Treatment
- 10-18 meter
- Centrifugal Pump
- <75 dB
- 0.4 MPa
- Industrial Grade
- Single Stage Pump
- 3-4 meter
- -10C to 80C
- 25 mm
- Electric
- 50/60 Hz
- Vertical / Horizontal
- 2800 rpm
- 0.5 to 2 HP
- Corrosion Resistant, Easy Installation, Maintenance-free
- Up to 6000 L/h
- 25 mm / 25 mm
- Mechanical Seal
- 0.3~0.6 MPa
Industrial Filter Pump Trade Information
- 50 Set Per Month
- 1 Week
Product Description
Our Filter Pumps are extremely popular in the marketplace. They are the top type of vacuum pumps that assists in lab filtration in which water inside a glass tube entrails air molecules from the system where it needs to be evacuated. The pumps helps in pulling the pool water from the skimmers on the pool as well. The water can be also pulled from main drains as well as near the bottom of the pool in such case using our reliable pumps. The quality filters of our pumps carefully segregates the dirt, debris as well as other impurities while pumping the water. The Filer Pumps are priced reasonably.
Features
- Our pumps have no operational or physical defects
- Our reliable pumps functions without any issues for a long period of time
- Our pumps are carefully designed to not just fit needs of clients but also in compliance to the standards
- Our pumps are extremely corrosion resistant
Specification
| Capacity | Up To 70 m3/h |
| Temperature (Degree Celsius) | 110 |
| Pressure (Megapascal) | 10 |
| Pump Type | Centrifugal |
| TDH | Up To 70 mtr |
Advanced Design for Durability and Performance
Featuring a closed impeller and single-stage structure, this pump ensures efficient fluid movement while minimizing wear. Its robust construction from PP or PVDF enhances chemical resistance, making it well-suited for aggressive industrial processes and high-safety environments.
Versatility in Installation and Usage
With options for threaded or flanged connections, vertical or horizontal suction, and manual or automatic control systems, this filter pump is engineered for versatility across various operational requirements. Its base-mounted, self-priming configuration allows for seamless integration into industrial setups.
Benefits of Reliable Industrial Filtration
Benefit from continuous, maintenance-free operation with a design that resists corrosion and tolerates up to 2% solid content in filtered fluids. Low noise output (<75 dB) and efficient air-cooled performance reduce operational disruptions, promoting safety and cost-effective, long-term usage.
FAQs of Industrial Filter Pump:
Q: How do I install the Industrial Filter Pump in my filtration system?
A: The pump offers flexibility for both vertical and horizontal suction configurations. Its base-mounted design, threaded or flanged connection options, and straightforward priming process allow for rapid and easy integration into a wide range of industrial filtration systems.Q: What applications is this pump most suitable for?
A: This filter pump is ideal for electroplating, chemical processing, and industrial water treatment where chemical resistance, efficient filtration, and durability are crucial. Its ability to handle up to 2% solid content makes it suited for challenging industrial environments.Q: When should I use the self-priming feature?
A: The self-priming feature should be used when the pump needs to handle fluids without manual priming, especially during starts after long shutdowns or when the pump is positioned above the fluid level, simplifying initial operation and maintenance.Q: Where can this pump be operated safely?
A: With IP55 protection, Class F insulation, and an air-cooled mechanism, the pump can be safely operated in most industrial settings with ambient temperatures ranging between -10C to 80C, including hazardous and corrosive environments.Q: What is the process for regular maintenance on this pump?
A: Designed for maintenance-free operation, the pump requires minimal routine checks. Mechanical seals and corrosion-resistant materials reduce the frequency of servicing, and basic inspections should focus on electrical connections and cleanliness of the inlet/outlet passages.Q: How does the pump benefit industrial operations?
A: It delivers a high flow rate (up to 6000 L/h), supports manual or automatic controls, and maintains quiet operation under 75 dB. Its corrosion resistance, reliability, and easy installation contribute to minimized downtime and long-term cost efficiency.Tell us about your requirement
